Laboratory Portable HOTPOT

Link Copied

Edit

Business Type	Manufacturer, Exporter, Supplier, Retailer
Material	Metal
Application	Laboratory Use
Weight	0-500kg, 1000-1500kg, 500-1000kg
Click to view more

Preferred Buyer From

Location

Worldwide

Product Details

Voltage

110V, 220V, 380V, 440V, 580V

Condition

New

Frequency

50Hz, 60Hz

Automatic Grade

Semi Automatic

Power

1-5kw, 5-10kw

Driven Type

Electric

Feature

Energy Saving Certified, Fast Heating, Rust Resistance, Shocked Proof

Warranty

5yrs

Storage Capacity

100-200L, 200-400L, 800-1600L

Has a Strong Durable Construction for Long Life Castable.
High Strength Rein Forced Refractory Top & Bottom.
Heavy Rugged Supported By Cast Alloys Structures.
Due to Heavy High Pressure Aluminum Carted Body Create Free Magnetic Path Within the Hot Pot and That’s Why Maximum Efficiency Provided.
Hydraulic Hand Pump Provided Ton An Emergency in Power Failure.
Easy, to Maintenance & Induction Copper Coil.
Eear Mechanism, Hoist Tilting Hydraulic Operated Tilting Mechanism Available.
One, Two &three Melting Hot Pot with Single Power Supply Source.
no Any Pedestal or Ordinary Bearing Use. Heavy Brass Busing Use for Long Life.
Husky Flat Copper Bus Bars are Used Instead of Tube Bus Bar to Put Maximum Power Into the Metal.
Steel Frame Structure for Higher Size Hot Pot.
Fully Captive Electromagnetic Flux Containment System.
Digital Ground Leak Detector Systems Provide Protection from Shock to the Operator & Damages
Single Uniform Design for Power Supply & Hot Pot Assembly.
Hand Operated Manual Mechanism.
Suitable for Ferrous & Non Ferrous Metals Including Precious Metals.
Wide Range of Suitable Parameters for Different Metal Alloying.
Provide Heavy Size of Horizontal & Vertical S.s Tie Roads Ensure Complete Structure Integrity.
Higher Size of Pure Copper Rope Use Into the Power Cable.
D.M Water Circulation Into the Power Cable to Reduce Water Flow Restriction & Long Life.
Provide Push and Lining Systems.

Specifications

Power KW	Input Voltage	KVA Demand	Cooling Tower Lpm at 42 to 32°C at 28°C Wetbulb Temp	Pump Rating at 35mtr Head	Cable Size Of Cu/Alu Sq.mm
50 75	415 415	52 80	90 110	0.75Hp/70Lpm 1.0H p/80Lmp	35/80 50/120
100 175	415 415	105 185	140 225	1.5Hp/100Lpm 1.5Hp/100Lpm	60/160 120/250
250 350	415 415	260 365	300 375	3Hp/150Lpm 3Hp/150Lpm	180/400 250/250*2
450 550	415 460	465 575	500 575	3Hp/150Lpm 4Hp/300Lpm	330/3302 400/4002
650 750	460 570	675 780	575 725	4Hp/300Lpm 4Hp/300Lpm	400/4002 400/4002
1000 1250	575 575*2	1040 1300	1150 1350	5H p/350Lpm 5H p/350Lpm	225×2/5202 350×2/3504
1500 2000	5752 5752	1575 2100	1550 2100	5H p/350Lpm 6H p/400Lpm	400×2/4004 550×2/5504
